Gazco Logic HE Beat Inset Gas Fire
A Choice of Three Fires
Logic HE (Logs)
Logic HE (Coals)
Logic Convector (Coals)
Adhering to the movement’s original concept, Gazco’s Arts gas fire echoes the style of the era whilst incorporating the latest inset gas fire innovations. It is available in the popular 16″ width as well as being offered with a wide choice of front and frame finishes.
You can select from our wide selection of sizes, colours, control systems and fuel effects for your inset gas fire.
Choose your style
Remote Control Options
Logic HE remote control fires offer complete convenience, allowing you to operate your fire from the comfort of your sofa. Your fire’s remote control options will depend on which fuel effect you choose.
Coal-effect Logic HE balanced flue remote control fires come with our standard handset, which allows you to adjust heat output and flame height. For greater control, you can select the optional Programmable Thermostatic handset, which lets you thermostatically control the room temperature as well as schedule your fire to switch itself on and off twice a day, once the pilot has been ignited.
Log-effect Logic HE fires and Coal-effect Logic HE conventional flue fires can be selected with our fully-sequential thermostatic handset. This advanced remote control allows you to ignite your fire and adjust the flame without getting up. This powerful control system can also set your Logic fire to maintain your preferred room temperature if desired.
*Logic HE Log-effect is only available with Slide Control and Remote Control options.
Slide Control
Gazco’s innovative slide system has a subtly designed, ergonomic control situated on the top right-hand side of the fire’s frame for easy access. This easy-reach lever offers complete and convenient control over the fire. Ignite or extinguish the fire as well as adjust flame height and corresponding heat levels to achieve the warmth and ambience you desire. Slide control Logic fires are available with a specific selection of frame styling options, please see the table below for details.
Logic HE Conventional Flue Coal-effect slide control fires feature a new injection moulded control handle which is cooler to the touch.
Manual Control
An easy-to-use system allows for ignition, extinguishing and full flame control all from a single control handle. To maintain the aesthetic appeal of your fire, the controls are discretely located behind the frame front at the bottom of the fire and can be accessed with ease.
Logic Front Choices
Arts
Chartwell
Wave
Logic Frame Choices
Arts2
Box Profil2
Logic™ Convector Conventional Flue
The Logic™ Convector open-fronted fire features a convection system that provides high-efficiency heat. Suitable for all chimney types, this realistic coal-effect (1) fire can be manual or remote.
The convector box draws cool room air into the bottom of the convection chamber (2). The air is warmed as it passes over the hot surfaces of the chamber (3) and then emitted back into the room via the top convection slot (4).
Logic™ HE Balanced Flue & Conventional Flue
The Logic™ HE features a glass front and boasts the highest efficiency of all the Logic Fires at up to 89%. The HE offers a choice of highly realistic log or coal fuel effects (1). With both conventional and balanced flue models, the HE is even suitable for homes without a chimney!*
The Logic HE box draws cool room air into the bottom of the convection chamber (2) the cool air is warmed as it passes over the hot surfaces of the chamber and the hot air is then emitted back into the room via the top convection slot (3). Maximum heat is radiated into the room via the virtually invisible glass front (4), with most models featuring specially designed non-reflective glass. The Logic HE balanced flue, Coal-effect fires have been specifically designed with reduced depth to allow for easy installation into the internal skin of a traditional cavity wall. Logic HE Coal-effect conventional flue fires feature specially moulded coals for added ease of installation.
* Balanced flue models only.
Manual & Remote Control Fires
| Logic Convector | Logic HE (logs) | Logic HE (coals) | ||
|---|---|---|---|---|
| Arts |  |
|
|
|
| Wave | |
|
|
|
| Chartwell | |
|
|
Slide Control Fires
| Logic Convector | Logic HE (logs) | Logic HE (coals) | ||
|---|---|---|---|---|
| Arts | |
|
|
|
| Wave | |
|
|
|
| Chartwell | |
|
|
Manual & Remote Control Fires
| Logic Convector | Logic HE (logs) | Logic HE (coals) | ||
|---|---|---|---|---|
| Arts | |
 |
|
|
| Box Profil | |
|
|
|
| Arts2 | |
|
|
|
| Box Profil2 | |
|
|
Slide Control Fires
| Logic Convector | Logic HE (logs) | Logic HE (coals) | ||
|---|---|---|---|---|
| Arts | |
|
|
|
| Box Profil | |
|
|
|
| Arts2 | |
|
|
|
| Box Profil2 | |
|
|
Key Features
| Logic Convector* | Logic HE | |
|---|---|---|
| Efficiency | 68.5% | CF: Up to 89% BF: Up to 86% |
| Heat output | Up to 4.20kW (input 6.70kW) | CF: Up to 3.90kW (input 5.20kW) BF: Up to 3.40kW (input 4.40kW) |
| Manual versions | |
|
| Slide control | |
|
| Remote control | |
|
| Fits into standard 410x560x250mm (wxhxd) fireplace opening |
|
|
| Fuel bed options | Coal | Coal & Logs |
| Convected heat | |
|
| Non-Reflective Glass♦ | |
|
| Radiant heat | |
|
| Wide selection of frames | |
|
| Natural Gas or LPG | |
|
| Can be wall mounted | |
|
| Ambient open fire | |
|
| Glass fronted high efficiency | |
|
| ODS (Oxygen Depletion Sensor)† | |
|
| Additional air vent required | |
|
| Conventional Flue | |
|
| Balanced Flue | |
|
| Energy Efficiency Class | F | B |
*This product is not suitable for primary heating purposes.
† ODS (Oxygen Depletion Sensor) – This safety feature will shut off the gas supply to the burner in the event of a reduction to oxygen levels in the room (conventional flue only).
♦ Not available to Logic HE Balanced Flue Coal-effect
